Say Hello to Mic, the World’s First Magnetic Induction Cycler.

The Mic ensures fast and highly accurate results. This real time PCR cycler is bundled into a small 2kg cube so you can bring it anywhere.

Now with a 3-year Standard Warranty.

REQUEST A DEMO
Mic Product Mobile

Superior qPCR data quality only comes from a rotary format!

Get accurate results, quickly and easily, in the lab or on the go.

Never be frustrated with your results again. Get BMS Australia’s real time PCR cycler that solves all your problems. Engineered in our facility in Australia, both our qPCR Cycler and automated Liquid Handling System have served our partner facilities across the US, Europe, and Asia.

Fast, small, and accurate, our PCR cycler will allow you to cut costs since technician servicing isn’t needed. Additionally, our lab instruments are also backed with intuitive software that will allow you to gather data seamlessly.

Integrating the Mic real time PCR cycler and the Myra liquid handling system can be your key tools to success.

There’s no other real time PCR instrument like it. The Mic qPCR cycler is built from the ground up for unmatched speed, reliability and accuracy.

The real time PCR instrument used by the World’s top institutes.

Feel Confident

Feel Confident in Your Results

The Mic PCR machine delivers unrivaled reproducibility between samples, runs and instruments so you can be confident in your results and your research.

Get results in less time

Get Results in Less Time

Completing runs in under
40 minutes is the new standard with Mic: not the exception. Maintaining assay performance even at speed ensures you can trust that data.

Mic Open

Intuitive software for easy use

Intuitive Software for Easy Use

Naturally, you want to be up and running as quickly as possible. So, installation for the Mic PCR instrument is plug-and-play and intuitive for a great user experience.

Feel confident in your results

Small and Portable for Convenience

Don’t be restricted by size if you’re on the road or in a small lab. Weighing in at just 2 kg, the Mic qPCR machine is the most portable and compact on the market. No servicing is required.

Why Mic is the only qPCR cycler you need

Speed

Speed

The Mic real time PCR cycler uses a patented magnetic induction technology to heat and fan forced air for cooling. This means fast quantitative real time PCR  PCR through rapid heating and cooling, with 35 cycles possible in under 25 minutes.

Back that up with a robust optical system that acquires all channels simultaneously. Running multiplexed qPCR assays has never been quicker. The Mic real-time PCR cycler is available in either 2 or 4 channel models.

Each channel uses an independent high intensity LED, photodetector, and filter set combined to give unparalleled detection performance. With a fixed optical path and no moving parts, there is never any optical alignment or calibration required with the Mic qPCR instrument. Even better is that no reference dyes or crosstalk compensation are needed.

Run Times Comparison

 Mic qPCR
 Vendor A
 Vendor B
 Vendor C
MIC

Accuracy

Accuracy

Mic delivers unrivalled reproducibility between samples, runs and instruments. Real time PCR cycler replicates have never looked so good, and detection of two-fold differences in gene expression levels never easier.

Why wait to run 384 samples? Get your results now and have the confidence your datasets can be seamlessly combined using our Projects analysis software. Comparing samples between multiple runs or even multiple instruments is effortless.

The Mic qPCR cycler incorporates a unique spinning aluminium rotor that has unsurpassed temperature uniformity during both dynamic and static operations. This functionality allows it to achieve the highest level of quantification precision. All other block-based real-time PCR thermal cyclers only promise static uniformity. This can lead to variability as samples aren’t heated and cooled at the same rate.

Combine Mic’s temperature accuracy of ±0.25ºC with a first class well-to-well temperature uniformity of ±0.05ºC (HRM units). Add superior equilibration time of zero seconds for all wells and you can easily classify difficult class IV SNPs that require melt temperature resolutions of less than 0.1ºC.

You might think this level of performance requires constant calibration of your machine, but Mic’s good to go right out of the box.

You don’t need to calibrate – ever.

Size

Mic takes up less space on the bench than your lab book. And weighing in at just 2kg, this is the most portable and compact qPCR machine on the market. Even four Mics stacked together take up less bench space than your current cycler.

Only magnetic induction technology by way of its elegant simplicity makes it possible to achieve such a small qPCR instrument footprint.

The Mic tube format uses 0.1mL strips of four tubes and matching caps, supporting volumes of 5 to 30µL. A tab on the first tube always ensures the correct orientation of tubes.

High speed centrifugation ensures samples spin down at the start of a run. While pre-loaded oil overlay inside each tube prevents evaporation and condensation. We have eliminated the need for bulky heated lids and external centrifuges whilst simultaneously improving the quality of results.

These benefits are only possible because of Mic real time PCR cyclers unique rotary and magnetic induction cycler technology. Take a minute to explore these research articles and see what Mic’s helped achieve already.

Mic Product

Connectivity

Multiple Mic real time PCR instruments can be operated from one workstation so 48 becomes 96, and 96 becomes 192. As many as 10 instruments can connect to one PC. Bluetooth technology means fewer cables, as well as seamless data transfer between the Mic qPCR cycler and the Myra liquid handler.

With the latest addition to Mic’s powerful software, it is easy to combine data from multiple runs from multiple machines into one dataset for analysis. Mic’s thermal and optical performance is so reproducible that your data will look like it was generated from the same real time PCR instrument.

Naturally, you want to be up and running as quickly as possible so installation for the instrument has been made plug-and-play. It’s as simple as installing the software and starting your first run.

decks pace icon

Rapid Capping Tool

Save time and effort capping all 48 tubes with the Rapid Capping Tool.

The Mic tubes come in strips of four with matching caps also racked in red coloured racks. Simply position the red racked caps on top of the black racked tubes, place them under the rapid tool and pull the handle down to secure all 48 tubes with caps.

Watch the video to see just how easy it is to cap tubes for the Mic real time PCR instrument.

Want to try before you buy?
Ordering a demo is simple.



01

Order a Demo

Press the ‘Request a demo’ button below and fill out the form. One of our distributors will be in contact within 24 hours to organise a Mic or Myra to be sent out to you.

02

Plug and play

Once delivered, install the software, turn the machine on and you are up and running. Our machines do not require a technician setup or difficult calibration.

03

Place an order

If you are satisfied after your two week trial, you can choose to purchase a machine of your own. Contact your distributor and they will organise payment and shipment.

We support the IAEA and the UN to deliver vital testing equipment to countries in need during the COVID-19 crisis.

1000+

whitepapers produced using the MIC

3000+

Mics sold to help with COVID-19

100+

Mics purchased by the IAEA to help with COVID-19

8000+

Mics sold worldwide

Lady in white lab coat

Mic | Specs

mic downloads image

Front

Mic qPCR Machine Rear View

Back


Physical

Height130 mm (265 mm lid open)
Width150 mm
Length150 mm
Weight2.1 kg

Thermal Performance

Temperature Accuracy±0.25°C
Temperature Uniformity±0.05°C (MIC-4+HRM)
±0.10°C (MIC-2 and MIC-4)
Ramp RatesHeating 4°C/s
Cooling 3°C/s
Temperature Input Range35 – 99°C

Optical

DetectorsPhotodiode per channel
Excitation SourcesHigh power LED for each channel
ChannelsGreenEx 465 nmEm 510 nm
YellowEx 540 nmEm 570 nm
OrangeEx 585 nmEm 618 nm
RedEx 635 nmEm 675 nm
Acquisition Time1 second

Reaction Tubes

Samples per Instrument48
Reaction Volume Range5 – 30 µL

Communication

TypeUSB 2.0 or Bluetooth
PC RequirementsWindows 8 (32 bit) OS, Intel i5 2.4 GHz or equivalent processor, 4GB RAM, 1GB HD, .NET Framework 4.5.

Operating Environment

Temperature18 – 30ºC
Relative Humidity20 – 80%

Electrical

AC Input100-240 VAC, 50/60 Hz 4.0 A

Compatible with any countries standard plugs/outlets
