list bullet Plug And Play, Superior qPCR data
list bullet No optical Calibration required
list bullet No thermal drift over time
list bullet No service contract necessary
Free demo

No risk, no obligation
14-day trial

Main hero image

FROM

£9,950

MIC 2 CHANNEL

Give Your Lab A Genuine qPCR Advantage!

The most robust qPCR system on the market.

Ultimate thermal and optical uniformity between all samples.

No variation from instrument to instrument.

decorative icon

Faster results

35 cycles in 25 minutes delivers precision and productivity

decorative icon

More accurate

Zero edge effect with best-in-class uniformity down to ± 0.05 degrees C

decorative icon

Compact and fully featured

Small, light, go-anywhere. And identical results in lab and field

decorative icon

Robust and reliable

For heavy-duty use. 2-year warranty and no annual maintenance required

decorative icon

Calibration-free

Mic qPCR has zero drift, so no calibration is ever needed

14 day no-risk, no
obligation demo.

The Mic ensures fast, highly accurate results

Quotes icon

BMS devices are effortlessly portable and intuitive, helping Cignpost to build a substantial distributed laboratory network to meet our client needs, often in remote locations, across the globe.

Richard Acton - CTO, Cignpost Diagnostics

Cignpost brand mark

Who's using Mic qPCR?

Anglia ruskin logo Anglia ruskin logo Anglia ruskin logo Anglia ruskin logo Anglia ruskin logo Anglia ruskin logo Anglia ruskin logo

Discover more

Hardware

Meet the world's first Magnetic Induction Cycler, from Bio Molecular Systems.

Software

Learn about the advanced automated statistical analysis in the micPCR software.

Why choose Mic?

Discover the features and benefits that make Mic the first choice for healthcare professionals and researchers everywhere.

Performance

Extraordinary accuracy, unrivalled reproducibility and extreme precision. That's Mic.

Gene Expression

Gene expression analysis with micqPCR Software can be achieved in 3 easy steps.

Download our software

We guarantee you'll find it user-friendly and packed with intelligent features.

14-day demo

Get started

Frequently Asked Questions

Can Mic run the same chemistry as my existing qPCR cycler?

Yes. The protocols for most assays will transfer to Mic without any changes. In some cases where a standard Taq polymerase is used (i.e. not specified to be compatible with fast cycling) we suggest you use the ‘Standard Taq Temperature Control’ option in the run profile. This slows down the heating rate of the Mic instrument to be closer to other instruments.

What is the difference between the previous generation Peltier Block based cyclers and Mic's patented induction technology?

The Magnetic Induction system used by Mic to heat the sample works on the same principle as an induction cooktop. The benefits over a peltier block based system are:

  • Fast cycling times (runs in less than 25 min)
  • Superior temperature uniformity (±0.05°C)
  • Only the rotor is heated - no need for thermal insulation
  • Mechanical simplicity results in one of the smallest real-time qPCR machines ever made
  • Rotary design allows us to incorporate an oil overlay ensuring no evaporation and no condensation. The oil overlay gives superior results and there is no need for a heated lid.

Can I run Mic in the field?

Yes. The portability and robustness of Mic is a huge advantage for anyone needing to do real time PCR in the field. Mic has proven to run reliably off batteries (car, truck or solar powered) using an inverter to supply between 100V and 240V AC.

What reaction volumes are compatible with Mic?

Yes. The protocols for most assays will transfer to Mic without any changes. In some cases where a standard Taq polymerase is used (i.e. not specified to be compatible with fast cycling) we suggest you Having flexibility in running different volumes is important to many users. Small volumes allow for significant reductions in reagent costs. Higher volumes allow for greater sensitivity in their test by increasing the chances of detecting the target. Mic maintains the same performance for any volume from 5 to 30μL. the ‘Standard Taq Temperature Control’ option in the run profile. This slows down the heating rate of the Mic instrument to be closer to other instruments.

Why does Mic not require calibration?

A thermal sensor is embedded in the spinning rotor which measures tube temperature directly. This sensor does not drift over time so there is no need for it to be recalibrated. For those customers who require an annual validation report, we have a Temperature Verification System.


Mic's optical system has a fixed optical path and no moving parts. This means there is never any need for optical alignment or calibration. Because every sample spins past the same detector there are no reference dyes or crosstalk compensation is required either.
