Get accurate results, quickly and easily.
Never be frustrated with your results again. Get BMS Australia’s real time PCR cycler that solves all your problems. Engineered in our facility in Australia, both our qPCR Cycler and automated Liquid Handling System have served our partner facilities across the US, Europe, and Asia.
Fast, small, and accurate, our PCR cycler will allow you to cut costs since technician servicing isn’t needed. Additionally, our lab instruments are also backed with intuitive software that will allow you to gather data seamlessly.
Why Choose Mic?
Feel Confident In Your Results
The Mic PCR machine delivers unrivaled reproducibility between samples, runs and instruments so you can be confident in your results and your research.
Get Results in Less Time
Completing runs in under 40 minutes is the new standard with Mic: not the exception. Maintaining assay performance even at speed ensures you can trust that data.
Intuitive Software for Easy Use
Naturally, you want to be up and running as quickly as possible. So, installation for the Mic PCR instrument is plug-and-play and intuitive for a great user experience.
Small and Portable for Convenience
Don’t be restricted by size if you’re on the road or in a small lab. Weighing in at just 2 kg, the Mic qPCR machine is the most portable and compact on the market. No servicing is required.
Ready to integrate the Mic qPCR into your lab?
Experience fewer errors, faster workflows, and the highest standard of precision.
Why Mic is the only qPCR cycler you need
Speed
The Mic real time PCR cycler uses a patented magnetic induction technology to heat and fan forced air for cooling. This means fast quantitative real time PCR PCR through rapid heating and cooling, with 35 cycles possible in under 25 minutes.
Back that up with a robust optical system that acquires all channels simultaneously. Running multiplexed qPCR assays has never been quicker. The Mic real-time PCR cycler is available in either 2 or 4 channel models.
Accuracy
Mic delivers unrivalled reproducibility between samples, runs and instruments. Real time PCR cycler replicates have never looked so good, and detection of two-fold differences in gene expression levels never easier.
Why wait to run 384 samples? Get your results now and have the confidence your datasets can be seamlessly combined using our Projects analysis software. Comparing samples between multiple runs or even multiple instruments is effortless.
Size
Mic takes up less space on the bench than your lab book. And weighing in at just 2kg, this is the most portable and compact qPCR machine on the market. Even four Mics stacked together take up less bench space than your current cycler.
Only magnetic induction technology by way of its elegant simplicity makes it possible to achieve such a small qPCR instrument footprint.
The Mic tube format uses 0.1mL strips of four tubes and matching caps, supporting volumes of 5 to 30µL. A tab on the first tube always ensures the correct orientation of tubes.
Connectivity
Multiple Mic real time PCR instruments can be operated from one workstation so 48 becomes 96, and 96 becomes 192. As many as 10 instruments can connect to one PC. Bluetooth technology means fewer cables, as well as seamless data transfer between the Mic qPCR cycler and the Myra liquid handler.
With the latest addition to Mic’s powerful software, it is easy to combine data from multiple runs from multiple machines into one dataset for analysis. Mic’s thermal and optical performance is so reproducible that your data will look like it was generated from the same real time PCR instrument.
Naturally, you want to be up and running as quickly as possible so installation for the instrument has been made plug-and-play. It’s as simple as installing the software and starting your first run.
Rapid Capping Tool
Save time and effort capping all 48 tubes with the Rapid Capping Tool. The Mic tubes come in strips of four with matching caps also racked in red coloured racks. Simply position the red racked caps on top of the black racked tubes, place them under the rapid tool and pull the handle down to secure all 48 tubes with caps.
Watch the video to see just how easy it is to cap tubes for the Mic real time PCR instrument.
Ready to integrate the Mic qPCR into your lab?
Experience fewer errors, faster workflows, and the highest standard of precision.
Used by the World’s Top Institutes
Mic Specifications
Measurements
| Height | 130mm (265mm lid open) |
| Width | 150mm |
| Length | 150mm |
| Weight | 2.1kg |
Thermal Performance
| Temperature Accuracy | ±0.25°C |
| Ramp Rates | ±0.05°C (MIC-4+HRM) ±0.10°C (MIC-2 and MIC-4) |
| Ramp Rates | Heating 4°C/s Cooling 3°C/s |
| Temperature Input Range | 35 – 99°C |
Optical
| Detectors | Photodiode per channel |
| Excitation Sources | High power LED for each channel |
| Channels |
|
| Acquisition Time | 1 second |
Reaction Tubes
| Samples per Instrument | 48 |
| Reaction Volume Range | 5 – 30 µL |
Communication
| Type | USB 2.0 or Bluetooth |
| PC Requirements | Windows 8 (32 bit) OS, Intel i5 2.4 GHz or equivalent processor, 4GB RAM, 1GB HD, .NET Framework 4.5. |
Operating Environment
| Temperature | 18 – 30ºC |
| Relative Humidity | 20 – 80% |
| Regulatory Classification | Research Use Only (RUO) |
Transport and Storage Conditions
| Temperature | 5 – 35ºC |
| Relative Humidity | 0 – 95% (no condensation) |
Ready to integrate the Mic qPCR into your lab?
Experience fewer errors, faster workflows, and the highest standard of precision.
